STAINLESS STEEL HONEY PROCESSING PLANT

Price 250000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

STAINLESS STEEL HONEY PROCESSING PLANT Specification

Phase
Three Phase

Function Type
Heating, Filtering, Homogenizing, Dehumidifying

Feeding System
Manual/Auto Feeder

Machine Type
Continuous Honey Processing Plant

Power Source
Electric

Speed Mode
Variable Speed

Operating Temperature
35C 50C

Noise Level
Low (<65 dB)

Heating Method
Indirect Steam Heating

Features
Easy Cleaning, CIP Compatible, Hygienic Design

Automation Grade
Automatic

Frequency
50/60 Hz

Product Type
Honey Processing Plant

General Use
Processing and Purification of Raw Honey

Material
Stainless Steel (Food Grade SS304/316)

Type
Industrial Processing Plant

Capacity
500-2000 kg/day

Weight (kg)
1850 kg (Approx)

Product Shape
Rectangular Modular Units

Computerized
Yes

Automatic
Fully Automatic

Control System
PLC Controlled

Installation Type
Fixed Installation

Voltage
380V

Power
15 kW

Dimension (L*W*H)
4200 x 2000 x 2300 mm

Raw Material
Raw Honey

Feature
High Purification Efficiency, Corrosion Resistant

Color
Metallic Silver

Inlet Connection
Tri-Clamp SS Fittings

Operation Mode
Continuous/Batch

Electrical Protection
IP54 Rated Panel

Working Pressure
0.5 2 Bar

Dehumidification Capacity
Adjustable Automatic Control

Cleaning System
Automatic CIP System

Environmental Compliance
Meets Food Safety Standards

Packaging Support
Integrated Transfer System for Bottling

Safety Features
Overload Protection, Emergency Stop

Service Support
Onsite Commissioning & Training

Filtration Precision
Up to 10 Microns

Main Components
Honey Heating Tank, Filter Tank, Homogenizer, Settling Tank, Dehumidifier Unit

Frame Type
Heavy Duty Welded Frame

Application Industries
Food Processing, Beekeeping Farms, Commercial Honey Manufacturing

Product Outlet
SS Sanitary Grade Outlet Valve

Ambient Temperature Range
10C 45C

About STAINLESS STEEL HONEY PROCESSING PLANT

ZIGMA MACHINERY & EQUIPMENT SOLUTIONS are Manufacturer, Supplier, Exporter of Various Fruits & Vegetable Pulp Processing Plants, Fruits & Vegetables Jam/Jelly Processing Plants, Fruits & Vegetables Juice Processing Plants,

Precision Filtration & Hygienic Design

This honey processing plant utilizes filtration technology capable of removing particles as small as 10 microns, ensuring a highly purified final product. Its food-grade stainless steel construction and advanced CIP cleaning system maintain strict hygiene standards, meeting all food safety regulations. The modular, rectangular design supports efficient operations and easy cleaning, ideal for continuous production environments.

Automated Dehumidification & Heating Process

Fully automated and PLC-controlled, the plant features adjustable dehumidification and indirect steam heating for optimal honey quality. The system's automatic control precisely manages humidity and temperature, supporting both continuous and batch operation modes. This results in consistent product texture and flavor, while maintaining the honey's natural properties.

Comprehensive Safety & Ease of Operation

Designed for ease and safety, the plant includes overload protection, emergency shut-off, and IP54-rated electrical panels. The integrated automatic cleaning system (CIP) enables effortless maintenance, and the user-friendly interface ensures smooth operation. Onsite commissioning and training are provided for quick setup, while the plant's robust frame and low-noise operation enhance workplace comfort.

FAQ's of STAINLESS STEEL HONEY PROCESSING PLANT:

Q: How does the Stainless Steel Honey Processing Plant improve honey purity?

A: The plant uses advanced filtration technology that removes particles down to 10 microns, combined with homogenization and dehumidification processes, resulting in highly purified honey with enhanced clarity and quality.

Q: What industries can benefit from this honey processing plant?

A: This processing plant is suitable for food processing companies, commercial honey manufacturers, and beekeeping farms, thanks to its efficient design and ability to handle large capacity operations ranging from 500 to 2000 kg per day.

Q: When is the best time to install and commission the honey processing plant?

A: Installation can be planned based on production schedules, and the manufacturer provides onsite commissioning and training to ensure proper setup and operation, ensuring minimal downtime during integration.

Q: Where is the plant typically installed and operated?

A: The plant is designed for fixed installation in industrial environments such as honey processing facilities, food production lines, or large farms. Its modular design can be adapted to various available spaces.

Q: What are the main steps in the honey processing workflow with this plant?

A: Raw honey is fed through tri-clamp stainless steel fittings into the heating tank, filtered and homogenized, passed through a dehumidification stage, settled, and then dispensed via the sanitary-grade outlet. Each step is controlled and monitored via PLC for quality assurance.

Q: How does the integrated cleaning system contribute to hygienic operations?

A: The automatic CIP (clean-in-place) system allows thorough cleaning of all processing components without disassembly, ensuring consistent hygiene and compliance with food safety standards.

Q: What are the advantages of using this plant over traditional honey processing methods?

A: Advantages include higher purification efficiency, precise control of quality parameters, automated continuous operation, enhanced safety features, reduced noise levels, and easy maintenance, all contributing to superior product quality and operational convenience.
