EGG TRAY DRYER MACHINE

Price 650000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

EGG TRAY DRYER MACHINE Specification

Function Type
Egg Tray Drying

Phase
Three Phase

Frequency
50/60 Hz

Machine Type
Industrial Egg Tray Dryer

Heating Method
Hot Air Circulation

Power Source
Electric

Noise Level
Low

Feeding System
Conveyor Belt

Speed Mode
Variable Frequency Drive

Automation Grade
Automatic

Features
Uniform Drying, Low Energy Consumption

Operating Temperature
120C - 180C

Product Type
Egg Tray Dryer Machine

General Use
Egg Tray Production Line

Material
Mild Steel

Type
Drying Machine

Capacity
1000-7000 pcs/hr

Weight (kg)
3200 kg

Product Shape
Rectangular

Computerized
No

Automatic
Yes

Control System
PLC Control

Installation Type
Floor Mounted

Voltage
380 V

Power
15 kW

Dimension (L*W*H)
7200 x 1800 x 2200 mm

Raw Material
Mild Steel

Feature
High Efficiency, Energy Saving

Color
Blue-Grey

Drying Chamber Material
Corrosion Resistant Steel

Application
Egg Tray, Fruit Tray, Industrial Pulp Molded Products

Safety System
Emergency Stop Button, Overload Protection

Ambient Humidity Range
85%

Installation Service
Available

Moisture Control
Adjustable Drying Time

Heating Efficiency
>85%

Exhaust System
Automatic Ventilation

Production Output
1000 to 7000 trays per hour

Service Life
Over 10 Years

Maintenance Access
Easy Access Panels

Air Flow System
Multi-pass Circulation

Conveyor Material
Stainless Steel Mesh Belt

Transport Mode
On Wheels

Door Type
Insulated Hinged Door

About EGG TRAY DRYER MACHINE

ZIGMA MACHINERY & EQUIPMENT SOLUTIONS are Manufacturer, Supplier, Exporter of Various Fruits & Vegetable Pulp Processing Plants, Fruits & Vegetables Jam/Jelly Processing Plants, Fruits & Vegetables Juice Processing Plants,

Efficient High-Capacity Drying

Achieve impressive throughput with a production output between 1000 and 7000 trays per hour. The advanced hot air circulation and multi-pass airflow system enable consistently uniform drying, meeting the demands of large-scale industrial egg tray lines.

Durable and Safe Construction

Built from corrosion-resistant steel, the insulated drying chamber ensures long-term durability and stable operation. Safety features like emergency stop, overload protection, and adjustable moisture control safeguard both operator and machinery.

Convenient Operation and Maintenance

With automatic PLC control and easy-access maintenance panels, the Egg Tray Dryer Machine streamlines daily use and servicing. Mounted on wheels for smooth transport, installation is straightforward, while low noise and energy-saving design enhance the workplace environment.

FAQ's of EGG TRAY DRYER MACHINE:

Q: How does the Egg Tray Dryer Machine ensure uniform drying across all trays?

A: The machine uses a multi-pass hot air circulation system and a stainless steel mesh belt conveyor, which distribute heat evenly, ensuring consistent drying results for every tray.

Q: What is the recommended usage process for drying egg trays in this machine?

A: Simply load wet trays onto the conveyor belt, set the desired drying time and temperature via the PLC control panel, and the machine automatically processes and dries trays with minimal manual intervention.

Q: When should moisture control adjustments be made during operation?

A: Moisture control adjustments are made based on the type of product and ambient humidity. Operators can fine-tune drying time on the control panel for optimal results whenever production materials or conditions change.

Q: Where can the Egg Tray Dryer Machine be installed, and what are the space requirements?

A: This machine is designed for floor-mounted installation in industrial egg tray production lines. Ensure a floor space of at least 7200 x 1800 mm, plus room for safe access to maintenance panels and ventilation.

Q: What safety features are integrated to protect operators and equipment?

A: Safety systems include an emergency stop button and overload protection mechanisms, designed to immediately halt operation in case of malfunction or excessive load, ensuring operator and equipment protection.

Q: What are the main benefits of using this dryer for pulp-molded products?

A: Benefits include high energy efficiency, uniform drying, low noise, easy maintenance, and a service life of over 10 years, making it ideal for efficient, reliable large-scale production.

Q: Is installation service available and what support is provided for setup?

A: Yes, professional installation service is available. The manufacturer provides expert assistance in setting up, calibrating, and testing the machine to ensure smooth integration into your production line.
