Rubber shredder

Name: Rubber shredder
Brand: ZIGMA MACHINERY & EQUIPMENT SOLUTIONS
Price: 750000 INR
Availability: InStock

Price 750000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Rubber shredder Specification

Frequency
50 Hz

Size
1800 x 1300 x 1600 mm

Weight
2500 kg

Capacity
800 kg/hr

Control System
PLC Controlled

Thickness
Up to 50 mm

Application
Industrial Rubber Shredding

Automatic Grade
Automatic

Motor Power
18.5 kW

Sheet Capacity
8 sheets

Color
Green

Processing Type
Shredding

Noise Level
Below 80 dB

Voltage
380 V

Material
High-grade Alloy Steel

Serviceability
Easy Maintenance Access

Safety Features
Emergency Stop Button, Overload Protection

Lubrication System
Automatic

Operation Temperature
-10°C to 40°C

Feeding Type
Conveyor Belt

Cutting Speed
12-15 rpm

Blade Diameter
320 mm

Number of Shafts
2

Discharge Type
Automatic Hopper

Blade Material
High-Cr Alloy Steel

Power Supply Phase
Three Phase

Rubber shredder About

ZIGMA MACHINERY & EQUIPMENT SOLUTIONS are Manufacturer, Supplier, Exporter of Various Fruits & Vegetable Pulp Processing Plants, Fruits & Vegetables Jam/Jelly Processing Plants, Fruits & Vegetables Juice Processing Plants,

Advanced Twin-Shaft Technology

This shredder utilizes a two-shaft mechanism for superior shredding performance and durability. Its 320 mm high-chromium alloy steel blades efficiently cut through thick rubber materials, making it ideal for industrial environments where heavy-duty processing is required.

Automated Safety and Operation

Equipped with emergency stop buttons, overload protection, and an automatic lubrication system, this shredder prioritizes operator safety and reliable performance. Its PLC-controlled automation enhances productivity while keeping operational risks to a minimum.

Easy Maintenance and High Productivity

Serviceability is streamlined through easy maintenance access, reducing downtime. The system's automatic feeding and discharge boost hourly capacity, handling up to 800 kg efficiently, perfect for demanding manufacturing and recycling facilities.

FAQ's of Rubber shredder:

Q: How does the twin-shaft shredding process work in this rubber shredder?

A: The shredder's twin shafts use synchronized, high-grade alloy steel blades to crush and tear rubber materials efficiently. The conveyor belt feeds the rubber to the cutting chamber, where rotating shafts break it into smaller pieces before automatic discharge via a hopper.

Q: What safety features are incorporated to protect operators during usage?

A: The shredder includes an emergency stop button for immediate shutdown, overload protection to prevent mechanical damage, and a PLC-controlled system for precise operational control. These features minimize risk and ensure safe operation in industrial settings.

Q: Why is high-Cr alloy steel used for the blades, and what are its benefits?

A: High-chromium alloy steel provides exceptional hardness, wear resistance, and durability. This material enables the blades to efficiently shred thick and abrasive rubber while maintaining a long service life and reducing the need for frequent replacement.

Q: When is automatic lubrication triggered, and how does it benefit maintenance?

A: The automatic lubrication system operates at programmed intervals, based on usage and load conditions set in the PLC control. This maintains optimal blade performance, minimizes friction, and significantly simplifies routine maintenance, leading to longer machine life.

Q: Where can this rubber shredder be installed, and what are its ideal applications?

A: This machine is designed for industrial use and can be installed in factories, recycling centers, or manufacturing facilities. It is ideal for large-scale shredding of rubber waste, tires, or sheets, supporting recycling operations and waste reduction initiatives.

Q: What is the maximum sheet thickness and processing capacity for this shredder?

A: The shredder handles rubber sheets up to 50 mm thick and can process up to 8 sheets at a time, with an overall capacity of 800 kg/hr, making it suitable for heavy-duty industrial applications.
